| PN | Functional Description | Frequency GHz |
Attenuation Range/Step （dB/dB） | Phase Shift Range /Step (°/°) | P1dB, dBm |
Gain, dB | Noise Figure, dB | Size, mm*mm |
Package | Datasheet |
| BSTCC11-01026S | Parallel port 6-bit phase shifter 6-bit attenuator amplifier & T/R switch |
0.9 – 1.3 | 32.1 / 0.6 | 360 / Rx:1.6 Tx:1.0 |
Rx: +14.0 Tx: +13.5 | Rx: 23.5 Tx: 21.0 | — | 5.15 × 3.75 | Die | – |
| BSTCC15-01035S | Amplifier 5-bit attenuator T/R Switch |
1 – 3 | 31.5 / 0.2 | — | 13 | 16 | 3,0 | 2.00 × 4.50 | Die | – |
| BSTCC13-02036S | Serial port 6-bit phase shifter 6-bit attenuator amplifier & T/R switch |
1.9 – 2.5 | 31.5 / 0.2 | 354 / 1.4 | 19 | 17 | — | 2.80 × 3.20 | Die | – |
| BSTCC27-02046S | Parallel port 6-bit phase shifter 7-bit attenuator |
2.5 – 3.5 | 31.75 / 0.25 | 354.375/5.625 | — | — | — | 2.75 × 2.35 | Die | – |
| BSTCC27-02046S2 | Serial port 6-bit phase shifter 7-bit attenuator |
2.5 – 3.5 | 31.75 / 0.1 | 354 / 1 | — | — | — | 2.85 x 2.70 | Die | – |
| BSTCC53-0513S | Parallel port 6-bit Phase shifter 6-bit attenuator |
5 – 13 | 31.5 / 0.5 | 354.375/5.625 | 16 | 8~11 | — | 3.50 x 4.00 | Die | – |
| BSTCC33-0713S | 4-channel 6-bit phase shifter 6-bit attenuator |
7 – 13 | 31.5/0.5 | 360/5.6 | Rx: -1 Tx: 15 | Rx: 5 Tx: 5 | 15,0 | 5.06 x 6.36 | Die | BSTCC33-0713S |
| BSTCC51-0713S | Parallel port 6-bit Phase shifter 6-bit attenuator |
7 – 13 | 31.5/0.5 | 354.375/5.625 | 11 | 12 | — | 4.50 x 3.50 | Die | – |
| BSTCC39-08116S | Serial port 6-bit Phase shifter 6-bit attenuator |
8.5 – 11 | 31.5/0.5 | 354.375/5.625 | 14 | RX: 13.5 Tx: 13 | 5,5 | 5.10 x 5.30 | Die | – |
| BSTCC03-0812S2 | 3-port,SIPO 6-bit phase shifter 6-bit attenuator T/R switch |
8 – 12 | 31.5/0.5 | 354.375/5.625 | 11 | 7.5~10 | — | 3.80 x 4.70 | Die | BSTCC03-0812S2 |
| BSTCC24-08126S | 2-port,SIPO 6-bit phase shifter amplifier & T/R switch |
10 – 12 | — | 354 / 1.4 | 18 | 13 | — | 4.50 x 2.20 | Die | – |
| BSTCC31-1418S | 4-channel 6-bit phase shifter 6-bit attenuator |
14 – 18 | 31.5/0.5 | 354.375/5.625 | Rx: 1 Tx: 14 | Rx: 4 Tx: 14 | 12,0 | 5.00 x 6.20 | Die | – |
| BSTCC60-1518S | 4-channel 6-bit phase shifter 6-bit attenuator |
15 – 18 | 31.5/0.5 | 360/5.625 | Rx: -26 | Rx: 16 Tx: 17 | 2,1 | 5.34 x 6.20 | Die | – |
| BSTCC34-3238S | 4-channel 6-bit phase shifter 6-bit attenuator |
32 – 38 | 31.5/0.5 | 360/5.6 | Rx: -31 Tx: 20 | Rx: 23 Tx: 25 | 5,5 | 4.875 x 4.471 | Die | – |
| BSTCC06-0513 | 4-channel 6-bit attenuator 6 phase shift control bits | 5 – 13 | 31.5/0.5 | 360/5.6 | Rx: 0 Tx: 17 | Rx: 4 Tx: 16 | 12,0 | 9×9 | QFN76 | BSTCC06-0513 |
| BSTCC32-0812 | 4-channel 6-bit attenuator 6 phase shift control bits | 8-12 | 31.5/0.5 | 360/5.625 | Rx: -24 Tx: 28 | Rx: 13.5 Tx: 19.5 | 3,0 | 9×9 | QFN76 | BSTCC32-0812 |
| BSTCC33-0713Q | 4-channel 6-bit attenuator 6 phase shift control bits | 7 – 13 | 31.5/0.5 | 360/5.6 | Rx: -1 Tx: 15 | Rx: 5 Tx: 5 | 16,0 | 8×8 | QFN68 | BSTCC33-0713Q |
| BSTCC35-1518 | 4-channel 6-bit attenuator 6 phase shift control bits | 15 – 18 | 31.5/0.5 | 360/5.625 | Rx: -25 Tx: 24 | Rx: 15 Tx: 16 | 3,1 | 9×9 | QFN76 | BSTCC35-1518 |
| BSTCC36-0812 | 4-channel 6-bit attenuator 6 phase shift control bits | 8-12 | 31.5/0.5 | 360/5.625 | Rx: -38 Tx: 28 | Rx: 12 Tx: 18 | 3,0 | 9×9 | QFN76 | BSTCC36-0812 |
| BSTCC58-1418 | 4-channel 6-bit attenuator 6 phase shift control bits | 14 – 18 | 31.5/0.5 | 360/5.625 | Rx: 1 Tx: 14 | Rx: 4 Tx: 14 | 13,0 | 8×8 | QFN68 | BSTCC58-1418 |
| BSTCC59-3238 | 4-channel 6-bit attenuator 6 phase shift control bits | 32 – 38 | 31.5/0.5 | 360/5.6 | Rx: -30 Tx: 21 | Rx: 23 Tx: 26 | 5,5 | 5.555×5.855 | WLCSP | BSTCC59-3238 |
